Insight: The Triumph of the Maltese Cross
The Maltese cross is a ubiquitous device found inside all sorts of mechanical movements. Originally devised to limit a mainspring’s working range, it also makes an appearance in perpetual calendars and unconventional jumping hours complications. The elegant mechanism is both simple and clever, warranting a closer look. From cross to mechanics The Maltese cross mechanism gets its name from the heraldic symbol adopted by the Order of St. John, and remains associated with the Sovereign Military Order of Malta. While the original cross has four arms, the Maltese cross as a horological component commonly features five arms or more. Collectors also recognise the cross as Vacheron Constantin’s logo, adopted in 1880 in tribute to the horological component. Today, Vacheron Constantin also incorporates the cross into its tourbillon cage and even some decorative screw heads. Screw for the column wheel fashioned with a Maltese cross head inside the Vacheron Constantin caliber 3200. The component itself is a masterfully simple example of geometry and mechanics. The system allows a true 1-to-any transmission ratio, since the driving component only has one tooth which makes the cross-shaped wheel advance one single step every revolution. For comparison, a 1:5 transmission ratio can be accomplished by a pinion with ten leaves paired to a wheel with 50 teeth, but the motion transmitted would then be continuous. A Maltese cross still makes one full revolution after the driver turns five...
